PVA Support Filament Atlas Support 1.75mm Natural 300 Gram 3D Printer Filament

Atlas Support

Atlas Support is the next generation in PVA water-soluble support materials for FFF/FDM 3D printing. Atlas Support is the result of extensive research to PVA improvement which has resulted in an unique formulation where numerous PVA grades have been blended into one superior water soluble support material with improved thermal stability.

Atlas Support has good bonding to a wide variety of materials – such as PLA, ABS, PETG, ASA, HIPS, et cetera  – and is much less sensitive to degradation by humidity.

Unique features

• Excellent water solubilityo
• Excellent support material for complex dual extrusion prints!
• Improved thermal stabilityo
• Much lesser risk of clogged nozzles caused by deteriorating/crystalizing material in (too) hot nozzle
• Good bonding to various (thermo)plastics
• Odourless processing
• Biodegradable once dissolved in water

General printing guidelines *

Nozzle size: ≥ 0.15mm	Layer height: ≥ 0.1mm	Flow rate: ± 100%
Print temp: ± 180 – 205° C *	Print speed: Medium	Retraction: Yes – 5mm
Heat bed: ± 0 – 60° C	Fan speed: 0-25%	Experience level: Expert

 *) Above displayed settings are meant as guidance to find your optimal print settings. These ranges in settings should work for most printers, but please do feel free to experiment outside these ranges if you think it is suitable for your printer. There are a lot of different type of printers, hot-ends and printer offsets that it is extremely difficult to give an overall one-size-fits-all setting.

*) Do not exceed a printing temperature of 225??à_C, because then PVA crystallizes quickly and it will no longer flow and/or dissolve in water. Printing with PVA materials does require a certain level of 3D printing expertise as PVA cannot stay too long in the hot secondary/support nozzle and needs to flow and by that needs expert tweaking to find the optimal “waiting temperature” for the material not to deteriorate/crystalizing in the hot secondary/support nozzle when not being printed.

Filament length

ρ: 1.22 g/cc	50 gr coil	0.3 Kg spool
Ø 1.75mm	± 17.0m	± 102m
Ø 2.85mm	± 6.4m	± 39m

Product export information

*) RoHS REACH compliance in accordance with: RoHS Directive 2011/65/EC — REACH Directive 1907/2006/EC.
